The AQ-4XL hydraulic drum cutter is an extremely popular model as it is an excellent fit for mid/large size excavators so commonly found on jobsites throughout the world (CAT 345/349, PC400/450 etc.). The impressive torque and cutting force output makes the AQ-4XL an excellent tool for mass excavation of medium to hard rock.
Recommended excavators/carrier size class: 45-70 tons
Hydraulic Power: 215HP (160kW)
| Technical Data | Unit | AQ-4XL |
|---|---|---|
| Cutting Head Diameter (B) | in (mm) | 28 (710) |
| Cutting Head Width (A) | in (mm) | 49 (1.245) |
| Oil Flow | gpm (l/min) | 65-130 (245-495) |
| Max Pressure | psi (bar) | 5,800 (400) |
| Max Torque | ft lbs (Nm) | 28,120 (38.125) |
| Max Cutting Force | lbs (N) | 24,068 (107.105) |
| Operating Weight | lbs (kg) | 5,775 (2.625) |
Please note hydraulic power rating should not be exceeded
Quantity of cutter bits for standard drums: 56
