AQ-3 Transverse Cutter

Antraquip AQ-3 Specification Sheet

The AQ-3 hydraulic cutter falls into the mid-size category and one of the more popular models of Antraquip drum cutters and is capable of operating on 12-20t carriers. This cutter is designed to efficiently cut soft to medium hard rock as well as concrete and provide impressive production rates. Commonly used for scaling, trenching, mine development and concrete profiling.

Recommended excavators/carrier size class: 12-20 tons
Popular rock grinding attachments for excavators in the 12-20 ton size class

Hydraulic Power: 90HP (65kW)

Technical DataUnitAQ-3
Cutting Head Diameter (B) in (mm) 22 (560)
Cutting Head Width (A) in (mm) 31 (790)
Oil Flow gpm (l/min) 30-45 (110-170)
Max Pressure psi (bar) 5,800 (400)
Max Torque ft lbs (Nm) 8,740 (11.850)
Max Cutting Force lbs (N) 9,545 (42.475)
Operating Weight lbs (kg) 2,045 (930)

Please note hydraulic power rating should not be exceeded

Hydraulic Drum Cutters from Antraquip

Quantity of cutter bits for standard drums: 48
